Drum Cleener

Drum washer

Modular drum washer

The Drum Cleener™ series is a drum washing system for degreasing smaller items. It is manufactured in modules, specified to suit customers requirements. The standard system, consist of washing, rinsing and drying modules, but can be expanded with several washing, rinsing, blowing and drying modules as needed.

Drum Cleener™ standard

As standard, the Drum Cleener™ is fully insulated and designed with easy access to internal parts via the gas-sprung doors. Parts are loaded manually or automatically from the production line. The Drum Cleener™ is equipped with Siemens PLC and HMI touch screen.

Ekstra equipment

Drum Cleener™ can be fitted with optional extra equipment, so that it is customised to suit the application. Drum Cleener™ can be connected directly to the production line or robot cell, so that it is only in operation when there are items for washing.

WE DELIVER THE BEST QUALITY IN THE INDUSTRY

Product Features

MODELS

DC 1025

DC 1040

DC 1050

DC 1060

Cleaning diameter

Ø250 mm

Ø400 mm

Ø500 mm

Ø600 mm

Cartridge filter 10”

400 µ

400 µ

400 µ

400 µ

Inlet- and outlet height

1120 / 750 mm

1120 / 750 mm

1120 / 750 mm

1120 / 750 mm

Machine width

1150 mm

1300 mm

1400 mm

1500 mm

Machine length - WNRD

2950 mm

2950 mm

2950 mm

2950 mm

Machine height

2100 mm

2100 mm

2100 mm

2100 mm

Drum speed

2-8 rpm

2-8 rpm

2-8 rpm

2-8 rpm

Tank capacity - wash / rinse

235/235 liter

235/235 liter

235/235 liter

235/235 liter

Wash pump - Stainless (standard)

CDX 200/20

CDX 200/20

CDX 200/20

CDX 200/20

Rinse pump - Stainless (standard)

CDX 120/12

CDX 120/12

CDX 120/12

CDX 120/12

Temperature

30>75℃

30>75℃

30>75℃

30>75℃

Pump capacity

60-210 l/min

60-210 l/min

60-210 l/min

60-210 l/min

Pressure / Amount of B-nozzels - wash/rinse

2 bar - 22/9 pcs

2 bar - 22/9 pcs

2 bar - 22/9 pcs

2 bar - 22/9 pcs

Heating - wash / rinse

9/9 kW

9/9 kW

9/9 kW

9/9 kW

Drying temperature

20>110℃

20>110℃

20>110℃

20>110℃
